Fan Motors
With outputs from 14 m³/h - 178 m³/h
A selection of high-quality fan motors for reliable cooling and ventilation.
All fan motors are equipped with ball bearings as standard and, in addition to the specified sizes, are also available in 40×40, 92×92 and 172×150.
Specification
| Article: | Fan Motors |
|---|---|
| Category: | Ventilation & Drainage |
Do you need more information?
Product Description
A selection of high quality fan motors.
All fan motors have "Ball bearing" as standard.
- In addition to the sizes below, there are also 40 × 40, 92 × 92, 172 × 150.
Drawing
Video
Documents & Other
| Art.No | Description | Air flow | Input voltage | Width mm | Height mm | Depth mm | Color | Unit | Pack Qty | Count | Offer |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 2E12B | Fan motor 2E | 39 cubic meters per hour | 12V DC | 60 | 60 | 25 | black | st | 1 | ||
| 2E24B | Fan motor 2E | 39 cubic meters per hour | 24V DC | 60 | 60 | 25 | black | st | 1 | ||
| 2E115B | Fan motor 2E | 14 cubic meters per hour | 115V AC | 60 | 60 | 25 | black | st | 1 | ||
| 2E230B | Fan motor 2E | 14 cubic meters per hour | 230V AC | 60 | 60 | 25 | black | st | 1 | ||
| 3E12B | Fan motor 3E | 67 cubic meters per hour | 12V DC | 80 | 80 | 25 | black | st | 1 | ||
| 3E24B | Fan motor 3E | 67 cubic meters per hour | 24V DC | 80 | 80 | 25 | black | st | 1 | ||
| 3E115B | Fan motor 3E | 54 cubic meters per hour | 115V AC | 80 | 80 | 25 | black | st | 1 | ||
| 3E230B | Fan motor 3E | 46 cubic meters per hour | 230V AC | 80 | 80 | 25 | black | st | 1 | ||
| 4E12B | Fan motor 4E | 178 m³/h | 12V DC | 120 | 120 | 38 | black | st | 1 | ||
| 4E24B | Fan motor 4E | 178 m³/h | 24V DC | 120 | 120 | 38 | black | st | 1 | ||
| 4E115B | Fan motor 4E | 167 cubic meters per hour | 115V AC | 120 | 120 | 38 | black | st | 1 | ||
| 4E230B | Fan motor 4E | 150 m³/h | 230V AC | 120 | 120 | 38 | black | st | 1 |
