Kylaggregat / Slim In

For wall or door mounting
500W - 4000W | IP54

Cooling unit / Slim In is a compact cooling unit with small dimensions for wall or door mounting, with cooling power from 500 to 4000 W.
The Slim In series is designed for applications where the unit should protrude minimally from the enclosure and is also available with UL certification.

Cooling unit Slim In

Specification

Article:Kylaggregat / Slim In
Category:Cooling Units
Brand:DKC
Protection class:IP54
Voltage:230V | 400/440V | 400/460V
Effect:500W - 4000W
Operating temperature:20°C - 50°C | 20°C - 55°C (UL)
Material:Steel sheet | Stainless steel AISI304L | Acid-resistant AISI316L (on request)
Color:RAL 7035 (steel sheet)

Do you need a price & more information?

Contact us for price & more information
DKC - logo

Cooling unit / Slim In with small expansion dimensions. For wall or door mounting, with an output of 500W – 4000W.

  • The cooling units are also available with UL certification.

Top version:

  • 2 PLUG-IN connectors for power supply
  • Control with alarm for overtemperature
  • Remote ON/OFF (door contact switch)
  • RS485 serial interface for remote control (ordered separately)

Other:

  • Built-in "hot-pipe" loop in the condensate tray that evaporates the condensate
  • Outer washable air filter
  • RAL7035
  • Other RALs are available
  • Visual alarm
  • RS485 serial protocol is available on request
  • Other power supply voltage possible
Art.NoDescriptionVersionCapacityInput voltage ACOperating temperature:Width mmHeight mmDepth mmProtection classColor / Material (housing)PDF
R5CND05021LITCooling unit Slim InTop500W230V20°C-50°C345690220IP54RAL7035PDF
RICND05021LITCooling unit Slim In | INOXTop500W230V20°C-50°C345690220IP54AISI304LPDF
R5CND10021SITCooling unit Slim InTop1000W230V20°C-50°C4901570195IP54RAL7035PDF
RICND10021SITCooling unit Slim In | INOXTop1000W230V20°C-50°C4901570195IP54AISI304LPDF
R5CND15021SITCooling unit Slim InTop1500W230V20°C-50°C4901570195IP54RAL7035PDF
RICND15021SITCooling unit Slim In | INOXTop1500W230V20°C-50°C4901570195IP54AISI304LPDF
R5CND20021SITCooling unit Slim InTop2000W230V20°C-50°C4901720220IP54RAL7035PDF
RICND20021SITCooling unit Slim In | INOXTop2000W230V20°C-50°C4901720220IP54AISI304LPDF
R5CND30021SITCooling unit Slim InTop3000W230V20°C-50°C4901720220IP54RAL7035PDF
RICND30021SITCooling unit Slim In | INOXTop3000W230V20°C-50°C4901720220IP54AISI304LPDF
R5CND30043SITCooling unit Slim InTop3000W400/440V 3-phase20°C-50°C4901720220IP54RAL7035PDF
RICND30043SITCooling unit Slim In | INOXTop3000W400/440V 3-phase20°C-50°C4901720220IP54AISI304LPDF
R5ULK30043SICooling unit Slim InTop UL3000W400/440V 3-phase20°C-55°C4901720220IP54RAL7035PDF
RIULK30043SICooling unit Slim In | INOXTop UL3000W400/440V 3-phase20°C-55°C4901720220IP54AISI304LPDF
R5CND40043SOTCooling unit Slim InTop4000W400/440V 3-phase20°C-50°C4051650220IP54RAL7035PDF
RICND40043SOTCooling unit Slim In | INOXTop4000W400/440V 3-phase20°C-50°C4051650220IP54AISI304LPDF

Download catalog

UL Certificate
