Peltier cooler
30W - 280W | IP65
Specification
| Article: | Peltier cooler |
|---|---|
| Category: | Cooling Units |
| Brand: | Rubsamen & Herr |
| Protection class: | PK30 IP43 (outside) | PK50-300 IP65 (outside) |
| Voltage: | 24V DC |
| Working temp: | -10° C ..+60°C |
| Other: | PK50 and PK100 are available in 12V |
Do you need a price & more information?
Product description
Efficient Peltier cooler for smaller cabinets and control panels. A more environmentally friendly alternative for cooling without liquid fluids. If you need cooling/heating but not the space, use a Peltier.
- Air conditioning for small cabinets, panels and control tables
- Environmentally friendly with thermoelectric cooling elements, without liquid refrigerant
- Separate inner and outer air cycles
- Small dimensions, function in all positions
- Heating and cooling function with one unit is possible and can be ordered as an option
Drawing
Article number
| Art.No | E-number | Description | Version | Capacity | Input voltage DC | Width mm | Height mm | Depth mm | Protection class | Material (enclosure) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| PK30 | 2599373 | Peltier cooler for cooling PK | INOX | Cooling | 30W | 24V | 160 | 112 | 130 | IP43 | AISI304L | |
| PK30HK | Peltier cooler for cooling PK/HK | INOX | Heating & Cooling | 30W | 24V | 160 | 112 | 130 | IP43 | AISI304L | ||
| PK50 | 2599375 | Peltier cooler for cooling PK | INOX | Cooling | 50W | 24V | 200 | 156 | 135 | IP65 | AISI304L | |
| PK50HK | Peltier cooler for cooling PK/HK | INOX | Heating & Cooling | 50W | 24V | 200 | 156 | 135 | IP65 | AISI304L | ||
| PK75 | 2599377 | Peltier cooler for cooling PK | INOX | Cooling | 75W | 24V | 250 | 203 | 145 | IP65 | AISI304L | |
| PK75HK | Peltier cooler for cooling PK/HK | INOX | Heating & Cooling | 75W | 24V | 250 | 203 | 145 | IP65 | AISI304L | ||
| PK100 | 2599378 | Peltier cooler for cooling PK | INOX | Cooling | 100W | 24V | 307 | 200 | 135 | IP65 | AISI304L | |
| PK100HK | Peltier cooler for cooling PK/HK | INOX | Heating & Cooling | 100W | 24V | 307 | 200 | 135 | IP65 | AISI304L | ||
| PK150 | 2599379 | Peltier cooler for cooling PK | INOX | Cooling | 150W | 24V | 307 | 200 | 135 | IP65 | AISI304L | |
| PK150HK | Peltier cooler for cooling PK/HK | INOX | Heating & Cooling | 150W | 24V | 307 | 200 | 135 | IP65 | AISI304L | ||
| PK300 | 2599381 | Peltier cooler for cooling PK | INOX | Cooling | 280W | 24V | 333 | 330 | 195 | IP65 | AISI304L | |
| PK300HK | Peltier cooler for cooling PK/HK | INOX | Heating & Cooling | 280W | 24V | 333 | 330 | 195 | IP65 | AISI304L |
