Heat exchanger Air / Water
2.25kW - 15kW
Air/water heat exchangers cool the inside of the enclosure using an internal water-borne cooling package.
Only an internal fan is used, eliminating the need for filters and external maintenance, but requires access to external cooling water.
Specification
| Article: | Heat exchanger Air / Water |
|---|---|
| Category: | Heat Exchangers |
| Brand: | Rubsamen & Herr |
| Protection class: | IP55 |
| Voltage: | 115V & 230V |
| Effect: | 2250W - 15000W |
| Color: | RAL7032 |
Do you need a price & more information?
Product description
Heat exchanger air / water, cools the inner part of the cabinet with the help of an inner water-borne cooling package.
Only internal fan which means no external maintenance of filters etc.
- Available external cooling water is required.
Drawing
Article number
| Art.No | Description | Capacity | Input voltage AC | Width mm | Height mm | Depth mm | Protection class | |
|---|---|---|---|---|---|---|---|---|
| BLU 18/115V | Air/water heat exchanger BLU | 1750W | 115V | 398 | 901 | 137 | IP55 | |
| BLUE 18 | Air/water heat exchanger BLU | 1750W | 230V | 398 | 901 | 137 | IP55 | |
| BIT 25/115V | Air/water heat exchanger BIT | 2250W | 115V | 400 | 270 | 542 | IP55 | |
| BIT 25 | Air/water heat exchanger BIT | 2250W | 230V | 400 | 270 | 542 | IP55 | |
| BLU 25/115V | Air/water heat exchanger BLU | 2500W | 115V | 398 | 901 | 137 | IP55 | |
| BLUE 25 | Air/water heat exchanger BLU | 2500W | 230V | 398 | 901 | 137 | IP55 | |
| BLU 35/115V | Air/water heat exchanger BLU | 3500W | 115V | 398 | 148 | 163 | IP55 | |
| BLUE 35 | Air/water heat exchanger BLU | 3500W | 230V | 398 | 148 | 163 | IP55 | |
| BLU 45/115V | Air/water heat exchanger BLU | 4500W | 115V | 398 | 1148 | 163 | IP55 | |
| BLUE 45 | Air/water heat exchanger BLU | 4500W | 230V | 398 | 1148 | 163 | IP55 | |
| BLU A0/115V | Air/water heat exchanger BLU | 10000W | 115V | 797 | 1932 | 206 | IP55 | |
| BLUE A0 | Air/water heat exchanger BLU | 10000W | 230V | 797 | 1932 | 206 | IP55 | |
| BLU A5/115V | Air/water heat exchanger BLU | 15000W | 115V | 797 | 1932 | 206 | IP55 | |
| BLU A5 | Air/water heat exchanger BLU | 15000W | 230V | 797 | 1932 | 206 | IP55 |
Accessories
Video
Document
