Spiralslang | SP/SPZ
Cable coil | Ø8 - 50mm | Halogen-free
Flexible Spiral Hose / SP/SPZ is a bendable spiral hose for protection and collection of cables, wires and hoses.
It can be easily retrofitted around existing cabling and provides a smooth connection between cabinets and door-mounted units.
Specification
| Article: | Spiral conduit / SP|SPZ |
|---|---|
| Category: | Spiral Wraps |
| Brand: | Partex |
| Material PVC: | Homogeneously colored PVC in cadmium-free quality according to Partex recipe, Self-extinguishing, UL94-V1 |
| Material Halogen-free: | Bayblend FR 3030, Halogen-free according to DIN/VDE 0472, section 81, Flame retardant, UL94-V0 |
| Temperature PVC: | -20°C -to +60°C |
| Temperature Halogen-free: | -30°C to +105°C |
| Length: | 1m |
| Color: | Grey / Green |
Do you need a price & more information?
Product description
Flexible Spiralslang | SP/SPZ for cable and wire routing is a tubular, flexible spiral hose. Excellent protection for wire bundles, cables, pipes, hoses, etc. Can be advantageously installed afterwards around wiring. Allows smooth connection between cabinets and door-mounted units. Also available in halogen-free version. Reduces cable and wire breakage and thus maintenance and downtime costs.
- Snap-in bracket that is threaded on before mounting holds the spiral conduit firmly in place.
Article number
| Art.No | Description | Type | Inner dia. Ø mm | Dia. Ø change | Meters | Color | Material |
|---|---|---|---|---|---|---|---|
| SP-08100KN | Spiral Wraps | Standard | 8 | +- 1 | 100 | Gray | PVC |
| SP-10100KN | Spiral Wraps | Standard | 10 | +- 1 | 60 | Gray | PVC |
| SPZ10100KN9 | Spiral hose | HF | Halogen free | 10 | +- 1 | 60 | Dark gray | Bayblend FR 3030 |
| SP-15100KN | Spiral Wraps | Standard | 15 | +- 1 | 40 | Gray | PVC |
| SPZ15100KN9 | Spiral hose | HF | Halogen free | 15 | +- 1 | 40 | Dark gray | Bayblend FR 3030 |
| SP-20100KN | Spiral Wraps | Standard | 20 | +- 1 | 40 | Gray | PVC |
| SPZ20100KN9 | Spiral hose | HF | Halogen free | 20 | +- 2 | 40 | Dark gray | Bayblend FR 3030 |
| SP-25100KN | Spiral Wraps | Standard | 25 | +- 1 | 30 | Gray | PVC |
| SPZ25100KN9 | Spiral hose | HF | Halogen free | 25 | +- 2 | 30 | Dark gray | Bayblend FR 3030 |
| SP-30100KN | Spiral Wraps | Standard | 30 | +- 1 | 20 | Gray | PVC |
| SPZ30100KN9 | Spiral hose | HF | Halogen free | 30 | +- 2 | 20 | Dark gray | Bayblend FR 3030 |
| SP-40100KN | Spiral Wraps | Standard | 40 | +- 1 | 10 | Gray | PVC |
| SPZ40100KN9 | Spiral hose | HF | Halogen free | 42 | +- 2 | 10 | Dark gray | Bayblend FR 3030 |
| SP-50100KN | Spiral Wraps | Standard | 50 | +- 1 | 4 | Gray | PVC |
Drawing
Accessories
| Art.No | Description | Max. thickness of mounting substrate (T) | Mounting hole (Ø) mm | Bracket mounting holes mm | Pc |
|---|---|---|---|---|---|
| SPH-1 | Bracket for spiral string | 3.2 | 6.2 | 8.1 x 2.3 | 50 |
