Efficient and safe cable management with Unex slotted cable ducts
Technical characteristics of the halogen free slotted trunkings
Slotted Duct:
Cable retainer:
Fulfilment of the highest standards
HL3-R22 enl./EN 45545-2
Unex Slotted trunkings 88 in U43X (own-formulated raw material) have successfully passed tests of fire safety according to EN 45545-2: 2013, meeting the requirements R22-R23 (both inside and outside railway vehicles) for hazard levels HL1 to HL3.
The objectives of EN 45545 are to minimize the probability of a fire starting, to control the rate and extent of fire development and through this, to minimize the impact of the products of fire on passengers and staff.
Moreover, Unex Slotted trunkings 88 have successfully passed the tests according to IEC 61373:2010 “Railway applications. Rolling stock equipment. Shock and vibration test”.
Burr-free slotted trunking
- Smooth design, without burrs or sharp edges: does not damage the user’s hand nor the cables during mounting.
- The cables insulation is not affected during transportation or in applications submitted to vibrations.
Cover
- Easy to mount and remove.
- In horizontal position, the fingers do not bend and the cover does not fall.
- In vertical position, the cover does not slide.
Solid and sturdy trunking
- Due to its solidity and sturdiness, the trunking can be suspended between rails.
- Few fixings required.
Cable holder
Only one part number for all trunking sizes
- The retainer can be cut according to the trunking’s width.
- It can be fixed at any adjustable height.
Advantages
with Unex slotted cable ducts HF:
- Flexible and durable Slots: The slotted sides have flexible and durable fingers that do not break during installation, which makes handling easier and reduces the risk of damage.
- Clean and safe design: The ducts have a smooth surface without burrs or sharp edges, which protects both the installer's hands and the cable insulation during installation.
- Stable and robust construction: Thanks to their solid structure, the ducts can be mounted between rails with fewer attachment points, simplifying installation and saving time.
- Effective cable holder: A rigid cable holder prevents deformations and allows for easy classification of circuits, contributing to organized and safe cable routing.
Technical characteristics:
- Temperature range: The ducts are designed to withstand temperatures from -45°C up to +90°C, making them suitable for various environments.
- Fire safety: The material is self-extinguishing and meets fire class V0 according to UL94, which means that it does not spread fire through droplets.
- Railway standard: The ducts meet the strictest requirements according to EN 45545-2 for use in railway vehicles, with the classification HL3-R22.
By choosing Unex slotted cable ducts HF, you get a reliable and safe solution for cable management that meets high demands on quality and functionality.
