Brush Plate Split / KEL-BES-S
For cable pass-through
KEL-BES-S is a split brush plate for cable entry in server racks, control panels and enclosures, developed for flexible cable entry even around existing cables.
The split frame allows for easy retrofitting while protecting cables from wear and tear and reducing airflow and dust ingress.
Specification
| Article: | Brush Plate Split / KEL-BES-S |
|---|---|
| Category: | Cable entries with brush seal |
| Brand: | icotek |
| Material: | Polyamide |
| Brush material: | Polyamide, Halogen-free, Silicone-free |
| Color: | Black (RAL 9005) |
| Flammability: | UL94-V0, self-extinguishing |
| Temperature: | −20°C to 90°C |
| Screw type mounting | 10 mm |
Do you need a price & more information?
Product description
Brush Plate Split / KEL-BES-S for routing cables to server racks, control panels and electrical cabinets.
The brush plates can either be mounted via screws or via expanding rivets. Due to the split frame, KEL-BES-S can also be installed around the cables.
- KEL-BES-S frame exactly matches the dimensions of 10/16/24 pin standard industrial connectors
Advantages:
- Quick and easy assembly (optional without screws)
- Retrofitting possible
- Versatile utilization
- Allows reduced airflow while filtering out dust, hair and larger particles
- Visuell screening
- Protects the cables against wear due to sharp edges when drilling holes
