Punches Round metric
In metric sizes from M16-M85.
Specification
Do you need a price & more information?
Product description
Punches round metric are self-centering knockout punches for stainless steel (V2A versions), mild steel, aluminum and plastic walls with max. thickness 3 mm (V2A: max. 2 mm). Punches available for punching PG16, M16, M20, M25, M32, M40, M50, M63, M75 and M85. Punching for all Icotek rounds cable entry systems is possible. The punch's special cutting geometry reduces the cutting pressure and thus the required effort. The punch splits the sheet into several pieces for easy removal. We also offer a PG16 (22.5mm) punch with integrated 3mm anti-rotation. The punches are also compatible with hand hydraulic punch tools from other manufacturers. The punches are designed for manual and hydraulic operation. Metric punches fit e.g. ours hydraulic tools.
- Compatible with: Punching tool set: BASIC, PRO 16-32 and PRO 16-63g.
- Suitable for eg article: KVT
- Material punch: Steel, hardened and polished
The delivery includes:
- Punch and counterweight (no draw stud)
Drawing
Article number
| Art.No | Size | Description |
|---|---|---|
| 80027 | PG16 | 22.5mm | Max wall thickness 2mm |
| 80028 | PG16(with anti-rotation) | 22.5mm | Max wall thickness 2mm |
| 80128 | PG16 V2A (R-free with anti-rotation) | 22.5mm | Max wall thickness 2mm |
| 80020 | M16 | 16.2mm | Max wall thickness 2mm |
| 80120 | M16 V2A(R-free) | 16.2mm | Max wall thickness 2mm |
| 80021 | M20 | 20.4mm | Max wall thickness 2mm |
| 80121 | M20 V2A(R-free) | 20.4mm | Max wall thickness 2mm |
| 80022 | M25 | 25.4mm | Max wall thickness 2mm |
| 80122 | M25 V2A(R-free) | 25.4mm | Max wall thickness 2mm |
| 80023 | M32 | 32.5mm | Max wall thickness 3mm |
| 80123 | M32 V2A(R-free) | 32.5mm | Max wall thickness 3mm |
| 80024 | M40 | 40.5mm | Max wall thickness 3mm |
| 80124 | M40 V2A(R-free) | 40.5mm | Max wall thickness 3mm |
| 80025 | M50 | 50.5mm | Max wall thickness 3mm |
| 80125 | M50 V2A(R-free) | 50.5mm | Max wall thickness 3mm |
| 80026 | M63 | 63.5mm | Max wall thickness 3mm |
| 80126 | M63 V2A(R-free) | 63.5mm | Max wall thickness 3mm |
| 80029 | M75 | 75.5mm | Max wall thickness 3mm |
| 80030 | M85 | 86.0mm | Max wall thickness 3mm |
