PTC-Värmare | SL

PTC heater with integrated fan | 250–650 W | 115 / 230 V

PTC heaters | SL are compact cabinet heaters with integrated fan and heating outputs from 250 to 650 W. The series has two separate heating circuits and built-in temperature monitoring that protects against overheating in the event of a fan failure.

Specification

Article:SL
Category:PTC Heaters
Brand:Rubsamen & Herr
Heat output:250W - 650W
Power supply voltage:115V / 230V AC, 50/60 Hz
Heating elements:PTC
Fan:Integrated
Connection:Spring clips
Montage:Screw / DIN rail
Color:Black

PRODUCT OVERVIEW

PTC heaters | SL includes four compact cabinet heaters with integrated fan. The series is available with heating outputs of 250, 350, 500 and 650 W at 20 °C.

All models use the same basic design. This simplifies installation when different control cabinet require different heating power.

The two heating circuits provide different connection options. Additionally, the fan and heating element can be connected separately.

An integrated temperature guard shuts off the heating when there is a fan failure to prevent overheating.

Properties

  • PTC heating element with integrated fan
  • Four power options: 250, 350, 500 and 650 W
  • Power supply voltage 230 V AC
  • Two heating circuits with different connection options
  • Separate connection for fan and heating element
  • Integrated temperature monitoring
  • Screw mounting or mounting on a DIN rail
  • Connection by spring terminals

Areas of use

The SL series is used in control cabinet where heating and active air circulation are required. The fan helps distribute the heat in the enclosure.

If necessary, supplement with a thermostat or hygrostat for automatic control of the heating.

Request a quote for PTC-Värmare | SL

Art.NoDescriptionCapacityInput voltageColourUnitPack QtyPDFCountOffer
SL250PTC heater with fan SL250W230V ACblackst1
SL250/115VPTC heater with fan SL250W115V ACblackst1
SL350PTC heater with fan SL350W230V ACblackst1
SL350/115VPTC heater with fan SL350W115V ACblackst1
SL500PTC heater with fan SL500W230V ACblackst1
SL500/115VPTC heater with fan SL500W115V ACblackst1
SL650PTC heater with fan SL650W230V ACblackst1
SL650/115VPTC heater with fan SL650W115V ACblackst1
