PTC Heater / SH|SM
Cabinet heaters 10W – 400W | 12V – 24V & 110V – 240V
PTC Heater / SH | SM is a compact and efficient heating solution for control cabinets and enclosures.
The smart design with aluminum profiles provides even heat dissipation and reliable operation at voltage ranges from 110–240 V, with output power from 10 W up to 400 W calculated from 20 °C.
Specification
| Article: | PTC Heater / SH|SM |
|---|---|
| Category: | PTC Heaters |
| Brand: | Rubsamen & Herr |
| Protection class: | IP54 SH10-45 & IP20 SH60-SH100L |
| Voltage: | 12V - 24V & 110V - 240V |
| Effect: | 10W - 400W |
| Color: | Black |
Do you need a price & more information?
Product description
PTC Heaters / SH|SM use innovative technology to generate up to 150W of heat. The smart design with aluminum profiles creates an efficient airflow that spreads the heat evenly throughout the enclosure. With a voltage range of 110 – 240V, you can be sure that this PTC heater will work no matter where in the world you are. Perfect for both the large control cabinet or the smaller enclosure, the reliable SH|SM series gives you the heat you need. Discover the benefits of our PTC heaters that combine powerful performance and smart design.
- Output effect:: Calculated from 20°C
- Effects from 10W up to 400W
Drawing
Article number
| Art.No | E-number | Description | Capacity | Input voltage DC | Input voltage AC | Width mm | Height mm | Depth mm | Protection class | Color | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SM10 | 2599331 | PTC Heater SM | 10W | 110-240V | 80 | 30 | 60 | IP54 | Black | ||
| SH20/24V | PTC Heater SM | 20W | 12-24V | 70 | 28 | 50 | IP54 | Black | |||
| SM20 | 2599335 | PTC Heater SM | 20W | 110-240V | 100 | 100 | 60 | IP54 | Black | ||
| SH30/24V | PTC Heater SM | 30W | 12-24V | 90 | 28 | 50 | IP54 | Black | |||
| SM30 | 2599337 | PTC Heater SM | 30W | 110-240V | 120 | 120 | 60 | IP54 | Black | ||
| SM45 | 2599339 | PTC Heater SM | 45W | 110-240V | 170 | 170 | 60 | IP54 | Black | ||
| SH60/24V | PTC Heater SH | 45W | 12-24V | 105 | 80 | 80 | IP54 | Black | |||
| SH60 | 2599706 | PTC Heater SH | 60W | 110-240V | 105 | 105 | 80 | IP20 | Black | ||
| SH75 | 2599707 | PTC Heater SH | 75W | 110-240V | 155 | 155 | 80 | IP20 | Black | ||
| SH100 | 2599710 | PTC Heater SH | 100W | 110-240V | 185 | 185 | 80 | IP20 | Black | ||
| SH150 | 2599715 | PTC Heater SH | 150W | 240V | 245 | 245 | 80 | IP20 | Black | ||
| SH250L/110V | PTC Heater SH | 250W | 110V | 155 | 155 | 80 | IP20 | Black | |||
| SH250L | 2599720 | PTC Heater SH | 250W | 240V | 155 | 155 | 80 | IP20 | Black | ||
| SH400L/110V | PTC Heater SH | 400W | 110V | 81 | 236 | 81 | IP20 | Black | |||
| SH400L | 2599725 | PTC Heater SH | 400W | 240V | 80 | 235 | 80 | IP20 | Black |
