Filter fan / LV
Free blow 15 m³/h - 930 m³/h
The LV filter fan is one of the market's most complete series with up to 15 performance classes and air flows from 15 to 930 m³/h.
The series is available in voltages from 12V DC to 400V AC and can be upgraded with Z-Line filters (F5) for increased protection up to IP55.
Specification
| Article: | Filter fan / LV |
|---|---|
| Category: | Filter Fans |
| Brand: | Rubsamen & Herr |
| Protection class: | IP54 & IP55 |
| Voltage: | 12V DC & 24V DC / 115V & 230V |
| Free blow: | 15m³/h - 930m³/h |
| Color: | RAL 7035 |
Do you need a price & more information?
Product description
Discover the most comprehensive series of filter fans on the market with Filter fan / LV from C-Pro. This series offers no less than 15 different performance classes, making it possible to adapt the fan to your specific needs. With an impressive output from 15 to 930 m³/h (free blowing), you can be sure of excellent results regardless of the application.
One of the great advantages of Filter fans / LV is their flexibility in terms of operating voltage. With available voltages from 12V DC to 400V AC, you can adapt the fan to your unique operating conditions. To further improve the protection of you can choose to upgrade with Z-Line filters of filter class F5, which gives you IP55. This not only guarantees optimal airflow, but also effective protection against dust and dirt.
- With our filter fans, you get a reliable and high-performance solution for air conditioning in Cabinets & Enclosures with the option of tailoring to your specific needs and requirements.
Drawing
Article number
| Art.No | E-number | Description | Power (free blow) | Input voltage DC | Input voltage AC | Width mm | Height mm | Depth mm | Protection class | Color | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| LV80/7035/12V | Filter fan LV | 15m³/h | 12V | 80 | 80 | 41 | IP54 | RAL7035 | |||
| LV80/7035/24V | 2599367 | Filter fan LV | 15m³/h | 24V | 80 | 80 | 41 | IP54 | RAL7035 | ||
| LV80/7035 | 2599907 | Filter fan LV | 15m³/h | 230V | 80 | 80 | 41 | IP54 | RAL7035 | ||
| LV80/7035/EMC | 2599907 | Filter fan LV | EMC | 15m³/h | 230V | 80 | 80 | 41 | IP54 | RAL7035 | ||
| LV100/7035/12V | Filter fan LV | 25m³/h | 230V | 105 | 105 | 55 | IP54 | RAL7035 | |||
| LV100/7035/24V | 2599368 | Filter fan LV | 25m³/h | 24V | 105 | 105 | 55 | IP54 | RAL7035 | ||
| LV100/7035/115V | Filter fan LV | 25m³/h | 115V | 105 | 105 | 55 | IP54 | RAL7035 | |||
| LV100/7035 | 2599850 | Filter fan LV | 25m³/h | 230V | 105 | 105 | 55 | IP54 | RAL7035 | ||
| LV100/7035/EMC | 2599850 | Filter fan LV | EMC | 25m³/h | 230V | 105 | 105 | 55 | IP54 | RAL7035 | ||
| LV200/7035/24V | 2599369 | Filter fan LV | 58m³/h | 24V | 130 | 130 | 72 | IP54 | RAL7035 | ||
| LV200/7035/115V | Filter fan LV | 58m³/h | 115V | 130 | 130 | 72 | IP54 | RAL7035 | |||
| LV200/7035/115V/EC | 2599307 | Filter fan LV | EC | 58m³/h | 115V | 130 | 130 | 72 | IP54 | RAL7035 | ||
| LV200/7035 | 2599870 | Filter fan LV | 58m³/h | 230V | 130 | 130 | 72 | IP54 | RAL7035 | ||
| LV200/7035/EMC | 2599870 | Filter fan LV | EMC | 58m³/h | 230V | 130 | 130 | 72 | IP54 | RAL7035 | ||
| LV200/7035/EC | 2599309 | Filter fan LV | EC | 58m³/h | 230V | 130 | 130 | 72 | IP54 | RAL7035 | ||
| LV250/7035/24V | 2599371 | Filter fan LV | 63m³/h | 24V | 148 | 148 | 65 | IP54 | RAL7035 | ||
| LV250/7035/115V | Filter fan LV | 63m³/h | 115V | 148 | 148 | 65 | IP54 | RAL7035 | |||
| LV250/7035/115V/EC | 2599311 | Filter fan LV | EC | 63m³/h | 115V | 148 | 148 | 65 | IP54 | RAL7035 | ||
| LV250/7035 | 2599871 | Filter fan LV | 63m³/h | 230V | 148 | 148 | 65 | IP54 | RAL7035 | ||
| LV250/7035/IP55 | 2599351 | Filter fan LV | 63m³/h | 230V | 148 | 148 | 65 | IP55 | RAL7035 | ||
| LV250/7035/EMC | 2599871 | Filter fan LV | EMC | 63m³/h | 230V | 148 | 148 | 65 | IP54 | RAL7035 | ||
| LV250/7035/EC | 2599301 | Filter fan LV | EC | 63m³/h | 230V | 148 | 148 | 65 | IP54 | RAL7035 | ||
| LV300/7035/24V | Filter fan LV | 115m³/h | 24V | 204 | 204 | 90 | IP54 | RAL7035 | |||
| LV300/7035/115V | Filter fan LV | 115m³/h | 115V | 204 | 204 | 90 | IP54 | RAL7035 | |||
| LV300/7035/115V/EC | 2599303 | Filter fan LV | EC | 115m³/h | 115V | 204 | 204 | 90 | IP54 | RAL7035 | ||
| LV300/7035 | 2599872 | Filter fan LV | 115m³/h | 230V | 204 | 204 | 90 | IP54 | RAL7035 | ||
| LV300/7035/IP55 | 2599353 | Filter fan LV | 115m³/h | 230V | 204 | 204 | 90 | IP55 | RAL7035 | ||
| LV300/7035/EMC | 2599872 | Filter fan LV | EMC | 115m³/h | 230V | 204 | 204 | 90 | IP54 | RAL7035 | ||
| LV300/7035/EC | 2599315 | Filter fan LV | EC | 115m³/h | 230V | 204 | 204 | 90 | IP54 | RAL7035 | ||
| LV405/7035/24V | Filter fan LV | 160m³/h | 24V | 250 | 250 | 102 | IP54 | RAL7035 | |||
| LV405/7035/115V | Filter fan LV | 160m³/h | 115V | 250 | 250 | 102 | IP54 | RAL7035 | |||
| LV405/7035 | 2599909 | Filter fan LV | 160m³/h | 230V | 250 | 250 | 102 | IP54 | RAL7035 | ||
| LV405/7035/IP55 | 2599355 | Filter fan LV | 160m³/h | 230V | 250 | 250 | 102 | IP55 | RAL7035 | ||
| LV405/7035/EMC | 2599909 | Filter fan LV | EMC | 160m³/h | 230V | 250 | 250 | 102 | IP54 | RAL7035 | ||
| LV410/7035/24V | Filter fan LV | 250m³/h | 24V | 250 | 250 | 120 | IP54 | RAL7035 | |||
| LV410/7035/115V | Filter fan LV | 250m³/h | 115V | 250 | 250 | 120 | IP54 | RAL7035 | |||
| LV410/7035 | 2599911 | Filter fan LV | 250m³/h | 230V | 250 | 250 | 120 | IP54 | RAL7035 | ||
| LV410/7035/IP55 | 2599357 | Filter fan LV | 250m³/h | 230V | 250 | 250 | 120 | IP55 | RAL7035 | ||
| LV410/7035/EMC | 2599911 | Filter fan LV | EMC | 250m³/h | 230V | 250 | 250 | 120 | IP54 | RAL7035 | ||
| LV410/7035/EC | Filter fan LV | EC | 250m³/h | 230V | 250 | 250 | 120 | IP54 | RAL7035 | |||
| LV500/7035/115V | Filter fan LV | 315m³/h | 115V | 250 | 250 | 132 | IP54 | RAL7035 | |||
| LV500/7035 | 2599874 | Filter fan LV | 315m³/h | 230V | 250 | 250 | 132 | IP54 | RAL7035 | ||
| LV500/7035/IP55 | 2599359 | Filter fan LV | 315m³/h | 230V | 250 | 250 | 132 | IP54 | RAL7035 | ||
| LV500/7035/EMC | 2599874 | Filter fan LV | EMC | 315m³/h | 230V | 250 | 250 | 132 | IP54 | RAL7035 | ||
| LV500/7035/400V | Filter fan LV | 315m³/h | 400V | 250 | 250 | 132 | IP54 | RAL7035 | |||
| LV550/7035 | 2599913 | Filter fan LV | 370m³/h | 230V | 250 | 250 | 125 | IP54 | RAL7035 | ||
| LV550/7035/IP55 | 2599361 | Filter fan LV | 370m³/h | 230V | 250 | 250 | 125 | IP55 | RAL7035 | ||
| LV550/7035/EC | Filter fan LV | EC | 370m³/h | 230V | 250 | 250 | 125 | IP54 | RAL7035 | |||
| LV600/7035/24V | Filter fan LV | 580m³/h | 24V | 323 | 323 | 148 | IP54 | RAL7035 | |||
| LV600/115V | Filter fan LV | 580m³/h | 115V | 323 | 323 | 148 | IP54 | RAL7035 | |||
| LV600/7035/230V | 2599875 | Filter fan LV | 580m³/h | 230V | 323 | 323 | 148 | IP54 | RAL7035 | ||
| LV600/7035/IP55 | 2599363 | Filter fan LV | 580m³/h | 230V | 323 | 323 | 148 | IP55 | RAL7035 | ||
| LV600/7035/EMC | 2599875 | Filter fan LV | EMC | 580m³/h | 230V | 323 | 323 | 148 | IP54 | RAL7035 | ||
| LV600/7035/EC | Filter fan LV | EC | 580m³/h | 230V | 323 | 323 | 148 | IP54 | RAL7035 | |||
| LV700/7035/115V | Filter fan LV | 730m³/h | 115V | 323 | 323 | 156 | IP54 | RAL7035 | |||
| LV700/7035 | 2599876 | Filter fan LV | 730m³/h | 230V | 323 | 323 | 156 | IP54 | RAL7035 | ||
| LV700/7035/IP55 | 2599365 | Filter fan LV | 730m³/h | 230V | 323 | 323 | 156 | IP55 | RAL7035 | ||
| LV700/7035/EMC | 2599876 | Filter fan LV | EMC | 730m³/h | 230V | 323 | 323 | 156 | IP54 | RAL7035 | ||
| LV700/7035/400V | Filter fan LV | 730m³/h | 400V | 323 | 323 | 156 | IP54 | RAL7035 | |||
| LV800/7035/115V | Filter fan LV | 930m³/h | 115V | 323 | 323 | 140 | IP54 | RAL7035 | |||
| LV800/7035 | 2599877 | Filter fan LV | 930m³/h | 230V | 323 | 323 | 140 | IP54 | RAL7035 | ||
| LV800/7035/IP55 | 2599366 | Filter fan LV | 930m³/h | 230V | 323 | 323 | 140 | IP55 | RAL7035 | ||
| LV800/7035/EMC | 2599877 | Filter fan LV | EMC | 930m³/h | 230V | 323 | 323 | 140 | IP54 | RAL7035 | ||
| LV800/7035/EC | Filter fan LV | EC | 930m³/h | 230V | 323 | 323 | 140 | IP54 | RAL7035 |
