Conduit / AGT ECOLINE
PA6 | UL94 V2 medium
For standard applications in: Mechanical Engineering, Automation, Energy, Construction, Railway
Protective hose / AGT ECOLINE is a flexible protective hose in PA6 with medium wall thickness for both standard applications and outdoor use.
It offers reliable mechanical protection and has a patented profile that, together with the ORJ O-ring, enables a higher IP class.
Specification
Do you need a price & more information?
Product description
Conduit / AGT ECOLINE is a flexible hose with medium thick walls in PA6, perfect for both standard applications and outdoor use. This innovative hose offers outstanding protection and versatility for your installations.
AGT ECOLINE is the perfect choice for those looking for a durable and versatile protective hose. With its unique combination of flexibility, durability and environmental friendliness, it is ideal for a variety of applications, from standard installations to demanding outdoor environments such as solar panel installations.
Choose Protective Hose / AGT ECOLINE for reliable protection and optimal performance in your projects. AGT has a special patented profile * to give the ORJ o-ring a higher IP class.
Well suited for standard applications in:
- Machine building
- Automation & Robotics
- Renewable energy installations
- Construction
- Railway industry
Drawing
Article number
| Art.No | Description | ND Ø mm | Internal Ø mm | External Ø mm | Meters | Color | Material |
|---|---|---|---|---|---|---|---|
| AGT-07N | Protective hose AGT | PA6 | 7 | 6.3 | 10 | 50 | Black | Polyamide 6 |
| AGT-10N | Protective hose AGT | PA6 | 10 | 9.7 | 13 | 50 | Black | Polyamide 6 |
| AGT-12N | Protective hose AGT | PA6 | 12 | 12.2 | 15.8 | 50 | Black | Polyamide 6 |
| AGT-17N | Protective hose AGT | PA6 | 17 | 16.8 | 21.2 | 50 | Black | Polyamide 6 |
| AGT-23N | Protective hose AGT | PA6 | 23 | 22.6 | 28.5 | 50 | Black | Polyamide 6 |
| AGT-29N | Protective hose AGT | PA6 | 29 | 28.3 | 34.5 | 50 | Black | Polyamide 6 |
| AGT-36N | Protective hose AGT | PA6 | 36 | 36.3 | 42.5 | 50 | Black | Polyamide 6 |
| AGT-48N | Protective hose AGT | PA6 | 48 | 47.4 | 54.5 | 50 | Black | Polyamide 6 |
| AGT-70N | Protective hose AGT | PA6 | 70 | 69.1 | 80.7 | 10** | Black | Polyamide 6 |
| AGT-95N | Protective hose AGT | PA6 | 95 | 91.7 | 106 | 10** | Black | Polyamide 6 |
** Other lengths on request
Accessories
Video
Document
You may also need...
PA6 | UL94 V0 medium
For applications with fire and smoke requirements: Automation, Railway, Construction, Marine
AISI304L | 2500N | 6J
For applications with high corrosion risk: Mechanical engineering, Automation, Energy, Construction, Railway, Marine
PA6 | UL94 V2 heavy
For standard applications in: Mechanical Engineering, Automation, Energy, Construction, Railway, Marine
Slotted | PA6 | UL94 HB light
For standard applications in: Mechanical engineering, Automation, Energy
Coupling | Bracket | O-Ring | Gasket
Do you need help choosing the right solution?
Choosing components is often about more than dimensions and threads.
Material choice, seals, IP class and environmental requirements affect both function and lifespan.
If you are unsure, we are happy to help you ensure that the solution works in your application.
