How to choose the right lighting
Choose the right lighting for safety and work environment
Having the right lighting in electrical cabinets and industrial environments is crucial for both safety and the work environment.
In this guide, we will go through how to choose the right solution based on cabinet size, environment and usage needs.
Our range of LED lighting for electrical cabinets
ALLIO
Compact LED lighting
Compact and energy-efficient fixture for smaller cabinets and standard applications.
- Compact format
- Single installation
- Low energy consumption
- IP20
ALLIO
2. ALU-LINE
For larger appliance cabinets
Robust LED luminaire in aluminum with high luminous flux for professional installations.
- Aluminium housing
- High brightness
- Long service life
- IP20
If ALU-LINE →
3. TUBE
For tough industrial environments
Impact-resistant and sealed LED luminaire for demanding environments with dust, moisture, and vibrations.
- IP67 - completely sealed
- Impact-resistant construction
- Chemical-resistant
- Long service life
The Tube
4. Striplite
Flexible LED luminaire
Small and flexible luminaire that fits where space is limited or for retrofitting.
- Subtle craftsmanship
- Multiple lengths
- Easy installation
- IP20
Se Striplite
5. LLX
Powerful LED lighting
Powerful 230V LED luminaire with very high luminous flux for large cabinets and tough requirements.
- Very high luminous flux
- 230V
- Robust construction
- IP20
Se LLX
IP classes – how to choose the right protection level
| IP class | Dust protection | Protection against water | Typical environments |
|---|---|---|---|
| IP20 | No protection against dust | No protection against water | Dry indoor environments, equipment cabinets |
| IP67 | Dammtät | Protection against temporary immersion | Machinery, process industry, dusty and humid environments |
Comparison of our LED luminaire series
| Property | ALLIO | ALU-LINE | Tube | Striplite | LLX |
|---|---|---|---|---|---|
| Voltage | 24V DC | 24V DC / 120–240V | 24V DC | 24V DC | 230V AC |
| Luminous flux | Low-Medium | Medium–High | Medium–High | Low-Medium | Very high |
| IP class | IP20 | IP20 | IP67 | IP20 | IP20 |
| Lengths | 350–1050 mm | 300–1350 mm | 250–3400 mm | 200–700 mm | 600–1200 mm |
| Mounting & Assembly | Screw / Magnet | Screw / Magnet | Screw | Screw / Magnet | Screw |
| Typical uses | Smaller cabinet | Larger cabinet | Tough environments | Tight spaces | Large cabinets, maximum light |
FAQ – How to choose the right lighting
Which lighting is best for small cabinets?
For smaller control cabinets, compact LED luminaires are recommended, such as ALLIO or Striplite. They take up little space, provide good brightness, and are easy to mount with screws or magnets. For most standard installations, a fixture with IP20 is sufficient.
Do I need IP67 in my cabinet?
IP67 is mainly needed when lighting is exposed to dust, moisture, or water, for example in process industries, food production, or outdoor applications. For standard equipment cabinets in dry indoor environments, IP20 is normally fully sufficient.
Can I connect multiple fixtures in series?
Yes. Several of our LED fixtures can be connected in series to provide even lighting in larger equipment cabinets or multiple cabinets in a row. Always check the respective product for maximum load and the number of fixtures that can be connected together.
How do I install LED lighting in an electrical cabinet?
Most LED luminaires can be mounted with screws or magnetic brackets depending on the model. Position the luminaire so that the entire work surface is illuminated and avoid shadows in front of components, terminals, and DIN rails. For larger cabinets, two or more luminaires can provide a more even light distribution.
Which fixture provides the most light?
For installations where the highest possible luminous flux is required, LLX-Series a good choice. It is developed for larger control cabinets and provides powerful lighting with 230 V power supply. For most standard installations, it also offers ALU-LINE very high brightness.
Which voltage should I choose – 24 VDC or 230 VAC?
24 VDC is often used in modern control cabinets because it can easily be connected to the control system's auxiliary voltage. 230 VAC is suitable when mains voltage is already available and high brightness is desired. The choice depends on the supply voltage available in the installation.
Is there lighting with sensors?
Yes. Several LED luminaires can be supplied with or supplemented with door sensors, motion sensors, or other control functions. Sensor control improves user-friendliness and reduces energy consumption by only switching on the lighting when it is needed.
How long is the lifespan of LED fixtures?
LED luminaires typically have a very long lifespan, often up to 50,000 operating hours or more depending on the model and operating environment. The long service life reduces maintenance needs and provides a low total cost of ownership compared to traditional lighting.
