Flexible Duct / DN-A
Flexible duct in Polypropylene
DN-A is a bendable and self-adhesive ribbed duct for flexible cable routing without the need for mounting holes.
It is particularly suitable for mobile installations, such as cabinet doors and hatches.
Specification
| Article: | DNA |
|---|---|
| Category: | Flexible Ducts |
| Brand: | IBOCO |
| Material: | Polypropylene |
| Temperature: | Max 100°C |
| Length: | 500mm |
| Color: | RAL7030 |
| Approvals: | CE, CSA |
Do you need more information?
Product description
Bendable adhesive and Flexible Duct / DN-A. For areas of use where mounting holes are not desired.
- A perfect solution for wiring to cabinet doors etc.
Drawing
Video
Documents & Other
| Art.No | E-number | Description | Width mm | Height mm | Length mm | Color | Unit | Saint Francis | Count | Offer |
|---|---|---|---|---|---|---|---|---|---|---|
| DN-AS | 2990275 | Rib Canal | DN-A | 17.3 | 23 | 500 | RAL7030 | fingerprint | 24 | ||
| DN-AM | 2990276 | Rib Canal | DN-A | 32 | 38.5 | 500 | RAL7030 | fingerprint | 24 | ||
| DN-AL | 2990277 | Rib Canal | DN-A | 42.5 | 48.5 | 500 | RAL7030 | fingerprint | 14 |
