Adapterinsats / AT-HA
Insert for industrial connectors 3A | 4A
IP65
AT-HA is an adapter insert in the modular IMAS-CONNECT™ system for industrial installations, developed for direct integration of 3A or 4A inserts into an adapter feed-through without additional drilling.
The adapter insert is based on a KT cable gland and is compatible with icotek's KT system as well as a wide selection of standardized contact housings.
Specification
| Article: | Adapterinsats / AT-HA |
|---|---|
| Category: | Cable glands for cables with connectors, Cable entry systems for cables with connectors |
| Brand: | icotek |
| Protection class: | IP54, IP55, IP64, IP65 |
| Material: | Elastomer |
| Material Base frame: | Polyamide |
| Flammability: | UL94-V0, self-extinguishing |
| Temperature: | −40°C to 100°C |
| Characteristics: | silicone-free, halogen-free |
| Type: | IMAS-CONNECT™ |
Do you need a price & more information?
Product description
Adapter insert / AT-HA is part of the IMAS-CONNECT™ modular adapter system and for the first time enables direct integration of 3A or 4A inserts into an adapter bushing – without the need for additional cutouts. The AT-HA bushing is based on a large KT cable bushing.
A robust polyamide body is integrated into the bushing. It is fully compatible with all icotek cable entry frames in the KT system and is delivered ready to use with a pre-mounted locking element. In combination with 3A or 4A insert sets and matching contact housings with M20 or M25 cable glands (see table) the AT-HA bushing offers a compact, efficient and flexible solution for use in industrial applications.
Adapter insert / AT-HA is also compatible with several insert manufacturers (Harting, Ilme, Phoenix Contact, TE Connectivity, Weidmüller, Lapp, Amphenol, Molex, RS Pro, …).
Advantages:
- Space-saving thanks to integration of the connector into the cable entry frame
- Can be combined with existing KEL frame solutions
- No additional drilling required
- Very easy to assemble
- Compatible with several manufacturers (e.g. Harting Han A)
- High protection class IP65 when connected
Drawing
Article number
Accessories
Video
Document
