Split cable gland / KVT-SNAP
Kan kopplas in | För kablar med kontakt
För håltagning M32 - M63
IP54
Specification
Article:
Split cable gland / KVT-SNAP
Category: Cable glands for cables with connectors
Brand: icotek
IP rating: | IP54 |
---|---|
Flammability: | UL94-V0, self-extinguishing |
Temperature: | −30°C till 100°C |
Material: | Polycarbonate |
Mounting options: | Fäst med låsmutter, Snap-in |
Characteristics: | Halogenfri, Silikonfri |
Betyg: 5/5
Vill du veta mer?
Product description
Split cable gland / KVT-SNAP is a circular split frame for quick and easy installation of cables with connectors or complete cable harnesses. By using the model KVT-SNAP, the cables can be pulled through thick walls (> 5 mm), e.g. through junction boxes without the use of tools. A sealing ring is included in the transport.
- The snap ring is screwed into metric thread or tapped into the cut-out (it can also be fastened with a locknut).
- Once the snap ring is affixed to the housing the equipped KVT is simply pushed into it.
Advantages:
- Genomföring av kablar med eller utan kontakt
- Warranties on pre-connected cables are maintained
- Remodeling, repairs and maintenance can be done much easier and faster
- High cable density, wide variety of grommets
- Suitable for metric hole punching
- Ökad packningstäthet vid användning av dubbla eller fyrdubbla genomföringar
- Simpel montage/demontage från frontsidan
Document
Download drawings
Tyvärr finns inga ritningar tillgängliga online för vald artikel.
Vänligen kontakta oss för mer information!
