Kabelförskruvningar EMC 4 Mässing
EMC 4 | Kabelförskruvningar med rörlig fjäderkontakt
Specification
| Article: | Kabelförskruvningar EMC 4 Mässing |
|---|---|
| Category: | Cable Glands EMC |
| Varumärke: | Bimed |
| Cable Gland material: | Brass |
| Sealing material: | Chloroprene |
| Clamping Insert material: | Polyamide PA6 |
| Contact Spring material: | Special Copper Allo |
| O-Ring Material | NBR |
| Protection class: | IP 69, IP 68 - 5 Bar, 30 min |
| Rating: | TYPE 4X |
| Flammability: | V2 according to UL94 |
| Operating temperature: | Permanent -20 °C to +100 °C |
| Thread type: | Metric |
| Certificate: | CE, UL, VDE, DNV |
Behöver du pris & mer information?
Betyg: 5/5
Product description
Cable glands EMC 4 / CBMEM is a high-performance solution for safe and efficient cable connection in demanding industrial environments. This specially designed EMC 4 protected cable gland offers exceptional performance and reliability for your critical applications. EMC 4 / CBMEM is specifically designed for use in metal machinery and enclosures where electromagnetic compatibility (EMC) is critical. It offers superior performance in industries that require reliable and safe cable connection with EMC 4 protection. This high-quality cable gland combines ease of use with state-of-the-art technology to ensure optimal performance in your EMC applications. Choose EMC 4 / CBMEM for a reliable, efficient and long-lasting solution for your cable connection needs.
- Vibration proof EMC performance.
- High contact performance under vibration thanks to reduced distance between clamping seal and EMC contact fingers.
- Long-lasting contact by high definition contact spring.
- Moving spring contact offers reduced risk of sheath damage.
- Open contact fingers when the gland cap is not tightened.
- Free rotational and axial movement of the cable without damaging the cable shield thanks to the open contact fingers.
- Low contact resistance thanks to large contact surfaces.
- Easy assembly and disassembly of cable. Spring closes and opens according to fastening of the cap.
- High quality strain relief and sealing, reliable performance for EMC applications.
- UL and VDE certified along with various other approvals - see technical data for full details
- Current international approvals.
Drawing
Article number
| Art.No | Description | Size | Cable diameter Ø mm | Shield Ø min-max mm | Thread Length TL mm | Height H mm |
|---|---|---|---|---|---|---|
| CBMEM–ES(M12T) | Cable gland EMC 4 brass | M12x1,5 | 3 – 6.5 | 2 – 5 | 6 | 30 |
| CBMEM-E1(M16T) | Cable gland EMC 4 brass | M16x1,5 | 5 – 10 | 3.5 – 8 | 6 | 35 |
| CBMEM-E2S(M20T) | Cable gland EMC 4 brass | M20x1,5 | 6 – 12 | 4.5 – 10 | 6 | 33.5 |
| CBMEM-E2(M20T) | Cable gland EMC 4 brass | M20x1,5 | 7.5 – 14 | 5.5 – 11.5 | 8 | 41.5 |
| CBMEM-E3(M25T) | Cable gland EMC 4 brass | M25x1,5 | 10 – 18 | 7 – 14 | 8 | 44.5 |
| CBMEM-E4(M32T) | Cable gland EMC 4 brass | M32x1,5 | 16 – 25 | 12 – 20 | 9 | 55 |
| CBMEM-E5(M40T) | Cable gland EMC 4 brass | M40x1,5 | 22 – 32 | 18 – 27 | 9 | 62.5 |
| CBMEM-E6(M50T) | Cable gland EMC 4 brass | M50x1,5 | 30 – 38 | 26 – 34 | 9 | 74 |
| CBMEM-E7L(M63T) | Cable gland EMC 4 brass | M63x1,5 | 37 – 53 | 33 – 49 | 10 | 75 |
