Junction Box / MBI-BK-M
Svart | Knockouts | PC | RAL9005 | IP66
Specification
| Article: | Junction Box / MBI-BK-M |
|---|---|
| Category: | Plastic Junction Boxes |
| Varumärke: | Multi-Box |
| Protection class: | IP66 |
| Material Botten: | Polykarbonat GF10 |
| Material Lock: | Polycarbonate |
| Sealing material: | Polyurethane |
| Material screws: | Plastic |
| Flammability: | V0 (Self-extinguishing) |
| Operating temperature: | -40°C to 100°C (permanent) |
| Color: | RAL 9005 |
| Impact resistance: | IK08 |
Behöver du pris & mer information?
Betyg: 5/5
Product description
Junction box / MBI-BK-M is the perfect combination of discreet presence, modern design and excellent technical performance. The base of the enclosure is designed with metric pre-punched knockouts on all four sides. These can be opened for cable entries.
- Lock levereras i svart i denna version.
Its all-black design integrates seamlessly into industrial environments and enables a discreet, almost invisible installation in factory halls, control cabinets, camera systems or elevator installations. Thanks to its design in elegant black color and clean shapes, MBI-BLACK boxes have a modern appearance.
Meets high technical requirements
Junction box / MBI-BK-M reliably meets the high technical requirements for industrial installation technology. MBI BLACK enclosures are made of fiberglass-reinforced polycarbonate. The material is UV-resistant (UL 746C F1) and self-extinguishing (UL 94 V0). With a seamless foamed 2-component polyurethane gasket, all types achieve protection class IP66. Cover screws are made of plastic material and are therefore completely corrosion-free. The impact resistance corresponds to IK08, which makes the MBI BLACK enclosures ideal for use in industrial and outdoor applications.
- UV-resistant
- Plastic screws for mounting are included in the delivery.
- MBI enclosures offer a variety of mounting points for direct fixation of components to the base.
Customize your box
Drawing
Article number
| Art.No | Description | Length | Width | Height | |
|---|---|---|---|---|---|
| 0906109760 | MBI-PC BK 090706 M | 94 | 65 | 57 | |
| 0906103960 | MBI-PC BK 130906 M | 130 | 94 | 57 | |
| 0906108960 | MBI-PC BK 180906 M | 180 | 94 | 57 | |
| 0906101170 | MBI-PC BK 111107 M | 110 | 110 | 66 | |
| 0906108390 | MBI-PC BK 181309 M | 180 | 130 | 90 | |
| 0906108890 | MBI-PC BK 181809 M | 182 | 180 | 90 | |
| 0906105810 | MBI-PC BK 251811 M | 254 | 180 | 111 | |
| 0906102230 | MBI-L-PC BK 202013 M | 200 | 200 | 130 | |
| 0906103230 | MBI-L-PC BK 302013 M | 300 | 200 | 130 | |
| 0906103380 | MBI-L-PC BK 303019 M | 300 | 300 | 185 | |
| 0906104380 | MBI-L-PC BK 403019 M | 400 | 300 | 185 |
