Box / E COR Nordic

Name: Box / E COR Nordic
Brand: E COR Nordic & Tillbehör
SKU: Kapsling / E COR Nordic
Rating: 5 (1 reviews)

Wall Box IP66
Incl. mounting plate
Cut-outs for FL21 in the top

Specification

Article:	Box / E COR Nordic
Category:	Cabinets in Steel Plate
Varumärke:	Eta
Protection class:	IP66 acc. to EN 60529 / NEMA 4 (IP55 double door)
Material:	Frame: 1.2 mm / Door: 2.0 mm / Mounting plate: 2.0 mm
Surface finish:	Epoxy powder coating, RAL 7035
Color:	RAL 7035 textured finish
Impact resistance:	IK10 acc. to IEC 62262
Seal:	Foam-molded polyurethane seal
Approvals:	CE, RoHS, TUV, RINA, EAC
FL21 cut-outs in roof:	2, 3, 4 or 5pcs

Betyg: 5/5

Do you want to know more?

Apparatskåp ECOR Nordic Front Singel Door

Product description

Box / E COR Nordic – Wall Box with mounting plate and FL21 cut-outs

E COR Nordic is a compact and durable wall-mounted enclosure from ETA's E COR series, designed to protect electrical and electronic equipment in demanding industrial environments. The enclosure is made of 1.2 mm Sendzimir galvanized steel sheet, which provides reliable corrosion protection and excellent mechanical strength.

The surface is treated with electrophoresis primer and powder coating in RAL 7035 (light grey) for additional protection and a professional appearance. The door is fitted with a polyurethane seal (foam-molded) and together with the fully welded construction provides tight protection according to IP66 / NEMA 4 and impact resistance IK10, making the enclosure suitable for both dusty and humid environments.

E COR Nordic is ideal for the Nordic market as the enclosure has cut-outs in the roof for FL21. The enclosure is delivered complete with door, mounting plate, and screw set for ground connection.

Included in delivery

Enclosure – Fully welded frame in 1.2 mm Sendzimir galvanized steel sheet, painted in RAL 7035.
Reversible door – Fitted with foam-molded seal and fitted with 3.0 mm double-bit locking system.
Mounting plate – In galvanized steel 2 mm.
Screw set – For grounding and internal mounting.

Can be equipped with

Wall brackets
FL21
Door stop
Various locking systems: padlock, key, ASSA system, etc.
Door profiles (horizontal)
Rain Roof
Door switch
Inner door
Modular kit
Accessories for adjusting the depth of the mounting plate
Base for free-standing mounting
Microperforated mounting plate
Tripod mount for outdoor installation

Document

Download drawings

Tyvärr finns inga ritningar tillgängliga online för vald artikel.
Vänligen kontakta oss för mer information!

Article number

Art.No	E-number	Description	FL21 Cut-outs	Width	Height	Depth
EC060630FL21_2		Single door \| Mounting plate	2	600	600	300
EC080830FL21_3	2505668	Single door \| Mounting plate	3	800	800	300
EC081030FL21_3	2505667	Single door \| Mounting plate	4	800	1000	300
EC101030FL21_4	2505666	Double door \| Mouting plate	4	1000	1000	300
EC101230FL21_4	2505664	Double door \| Mouting plate	4	1000	1200	300
EC101430FL21_4	2505665	Double door \| Mouting plate	4	1000	1400	300
EC121230FL21_4	2505663	Double door \| Mouting plate	4	1200	1200	300
EC121430FL21_4	2505662	Double door \| Mouting plate	4	1200	1400	300
EC141430FL21_5	2505661	Double door \| Mouting plate	5	1400	1400	300

Accessories

Art.No	Type	Description	Passar skåp
HTC-3	FL21 Multifläns 3	2×24-54, 1×30-59 3×6-14	EC060630FL21_2
HTC-16	FL21 Multiflange 16	1x dia.40, 15x dia.20	EC060630FL21_2
HTC-17	FL21 Multiflange 17	9×18-30 el. 9×10-14, 4×10-15, 4×5-10	EC060630FL21_2
HTC-25	FL21 Multiflange 25	1×20-26 el. 12×15, 16×8-14 el. 7-10, 4×14-20 el. 5-10, 4 5-7	EC060630FL21_2
HTC-28	FL21 Multiflange 28	18×6-13, 6×13-28, 4×3-11	EC060630FL21_2
HTC-35	FL21 Multiflange 35	1×17-32, 2×12-18, 16×10-14, 12×7-12, 4×6-10	EC060630FL21_2
HTC-36	FL21 Multiflange 35	4×4-8, 4×6-10, 11×7-11, 14×10-14, 2×12-18, 1X17-32	EC060630FL21_2
HTC-43	FL21 Multifläns 43	4×4-10,5, 38×7-12,5, 1×14-27,5	EC060630FL21_2
HTC-50	FL21 Multiflange 50	49×7-13, 1×15-25	EC060630FL21_2
HTC-0	FL21 Multifläns	Slät	EC060630FL21_2
